Product Overview
1 1/2" QED Pressure Gauge 0-1500 PSI, PN 1700-54, NSN 6685-01-172-5334
PN: 1700-54
NSN: 6685-01-172-5334
OVERALL DEPTH: 0.900 INCHES NOMINAL
OVERALL DIAMETER: 1.720 INCHES NOMINAL
CASE MATERIAL: ALUMINUM ALLOY
CASE SURFACE TREATMENT: ANODIZED BLACK
END ITEM IDENTIFICATION: AIRCRAFT,STRATOLIFTER C-135
GRADUATION UNIT: 500.0 POUNDS PER SQUARE INCH
ACTUATION TYPE: BOURDON TUBE
ADJUSTABILITY: ADJUSTABLE OR
ADJUSTABILITY: NONADJUSTABLE
SCALE RANGE: 0.0 TO 1500.0 POUNDS PRESSURE PER SQUARE INCH
SCALE NAME: PRESSURE
CONNECTION QUANTITY: 1
POINTER COLOR: BLACK
POINTER TYPE: INDICATING
SCALE TYPE: SINGLE
SCALE SMALLEST INCREMENT: 50.0 POUNDS PER SQUARE INCH
CONNECTION TYPE: EXTERNAL
MOUNTING METHOD: SURFACE
SCALE ACCURACY : PORM 20 PSI AT 600 PSI,PORM 30 PSI BETWEEN 400 AND 800 PSI,PORM 45 PSI AT LOW AND HIGH ENDS OF SCALE
ACTUATING ELEMENT MATERIAL: NICKEL-CHROMIUM-IRON ALLOY, MIL-T-7840
SCALE INSCRIPTION/BACKGROUND COLOR: BLACK MARKINGS ON WHITE BACKGROUND
CONNECTION LOCATION: BACK
PROTECTIVE CRYSTAL MATERIAL: GLASS
CONNECTION SIZE: 0.125 IN. NPT DIA
CONNECTOR TYPE VENT: NOT PROVIDED
New surplus item without original packaging. Please see photos for more.
XXQXX07
PN: 1700-54
NSN: 6685-01-172-5334
OVERALL DEPTH: 0.900 INCHES NOMINAL
OVERALL DIAMETER: 1.720 INCHES NOMINAL
CASE MATERIAL: ALUMINUM ALLOY
CASE SURFACE TREATMENT: ANODIZED BLACK
END ITEM IDENTIFICATION: AIRCRAFT,STRATOLIFTER C-135
GRADUATION UNIT: 500.0 POUNDS PER SQUARE INCH
ACTUATION TYPE: BOURDON TUBE
ADJUSTABILITY: ADJUSTABLE OR
ADJUSTABILITY: NONADJUSTABLE
SCALE RANGE: 0.0 TO 1500.0 POUNDS PRESSURE PER SQUARE INCH
SCALE NAME: PRESSURE
CONNECTION QUANTITY: 1
POINTER COLOR: BLACK
POINTER TYPE: INDICATING
SCALE TYPE: SINGLE
SCALE SMALLEST INCREMENT: 50.0 POUNDS PER SQUARE INCH
CONNECTION TYPE: EXTERNAL
MOUNTING METHOD: SURFACE
SCALE ACCURACY : PORM 20 PSI AT 600 PSI,PORM 30 PSI BETWEEN 400 AND 800 PSI,PORM 45 PSI AT LOW AND HIGH ENDS OF SCALE
ACTUATING ELEMENT MATERIAL: NICKEL-CHROMIUM-IRON ALLOY, MIL-T-7840
SCALE INSCRIPTION/BACKGROUND COLOR: BLACK MARKINGS ON WHITE BACKGROUND
CONNECTION LOCATION: BACK
PROTECTIVE CRYSTAL MATERIAL: GLASS
CONNECTION SIZE: 0.125 IN. NPT DIA
CONNECTOR TYPE VENT: NOT PROVIDED
New surplus item without original packaging. Please see photos for more.
XXQXX07
