Product Overview
3D Instruments Pressure Guage 0-300 PSI PN: 25552-26B21 NSN: 6685-01-214-2572
Overall Depth: 2.060 inches nominal
Overall Diameter: 3.250 inches nominal
Case Surface Treatment: Paint, black
Graduation Unit: 50.0 pounds per square inch
Actuation Type: Single coil helical bourdon tube
Adjustability: Adjustable
Scale Range: +0.0 to 300.0 pounds pressure per square inch
Scale Name: Pressure
Dial Size: 2-1/2 in. dia
Connection Quantity: 1
Pointer Color: Black
Pointer Type: Indicating
Scale Type: Single
Scale Smallest Increment: 5.0 pounds per square inch
Connection Type: External
Mounting Method: STUD
Stud Quantity: 2
Scale Accuracy: Porm 1/2 pct full scale
Actuating Element Material: Nickel-chromium-iron alloy, MIL-T-7840
Scale Inscription/Background Color: Black markings on white background
Connection Location: BACK
Bezel Type: Snap-on
Protective Crystal Material: Plastic
Connection Size: 0.250 in. npt dia
Stud Location: BACK
Connector Type Vent: Not provided
Surface Treatment: Paint
New surplus. See photos for more details.
