| MRC |
Requirements |
Characteristics |
| STYL |
STYLE DESIGNATOR |
ROUND FLUSH MTG |
| BHSX |
UNABLE TO DECODE |
UNABLE TO DECODE |
| APSN |
UNABLE TO DECODE |
UNABLE TO DECODE |
| ABHP |
OVERALL LENGTH |
1.725 INCHES NOMINAL |
| ADAV |
OVERALL DIAMETER |
2.695 INCHES NOMINAL |
| BHDC |
SCALE GRADUATION TYPE |
LINEAR SINGLE INDICATOR SINGLE RANGE |
| ABWG |
SCALE DIVISION QUANTITY |
50 SINGLE INDICATOR SINGLE RANGE |
| ASSS |
POINTER COLOR |
BLACK SINGLE INDICATOR SINGLE RANGE |
| AMKD |
INDICATOR TYPE |
DIAL W/POINTER |
| AMQY |
III INSTALLATION DESIGN |
PANEL |
| NHCF |
NUCLEAR HARDNESS CRITICAL FEATURE |
NONHARDENED |
| AQEC |
MOVEMENT TYPE |
MOVING COIL, PERMANENT MAGNET |
| CTQL |
MOVEMENT SUSPENSION METHOD |
JEWEL PIVOT BASE |
| ADAG |
MOUNTING STUD LENGTH |
0.375 INCHES NOMINAL |
| BLKZ |
MOUNTING STUD DIAMETER |
0.125 INCHES NOMINAL |
| AXHR |
MOUNTING FACILITY TYPE AND QUANTITY |
3 THREADED STUD |
| AFFL |
MOUNTING BOLT CIRCLE DIAMETER |
2.220 INCHES NOMINAL |
| ANRL |
MOUNTING ARRANGEMENT STYLE |
THREE HOLE/STUD BOLT CIRCLE |
| APSW |
METER BODY DIAMETER BEHIND MOUNTING FLANGE |
2.205 INCHES NOMINAL |
| APST |
METER DEPTH BEHIND MOUNTING FLANGE |
1.495 INCHES NOMINAL |
| BHMW |
MEASUREMENT RANGE |
+0.0/+5.0 AMPERES, AC SINGLE INDICATOR SINGLE RANGE |
| MATT |
MATERIAL |
STEEL |
| ZZZV |
FSC APPLICATION DATA |
TEST SET ELECTRONIC |
| APMM |
DIAL SCALE MARKING COLOR |
BLACK SINGLE INDICATOR SINGLE RANGE |
| AACT |
CIRCUIT CURRENT FOR WHICH DESIGNED |
AC |
| CTTD |
CIRCUIT ATTACHMENT METHOD AND QUANTITY |
2 SOLDER LUG |
| AQFY |
BACKGROUND COLOR |
WHITE SINGLE INDICATOR SINGLE RANGE |
| APPN |
ACCURACY IN PERCENT |
-2.0/+2.0 AT FULL SCALE SINGLE INDICATOR SINGLE RANGE |
