Product Overview
Danaher Controls Rotating Counter
NSN: 6540-01-146-4278
PN: 2630
|
 |
OVERALL WIDTH |
1.500 INCHES NOMINAL | ||
|
 |
OVERALL LENGTH |
2.734 INCHES NOMINAL | ||
|
 |
OVERALL HEIGHT |
1.468 INCHES NOMINAL | ||
|
 |
SHAFT ROTATION DIRECTION AND MAXIMUM SPEED IN RPM |
800.0 CLOCKWISE SINGLE REGISTER SINGLE TIER AND 800.0 COUNTERCLOCKWISE SINGLE REGISTER SINGLE TIER | ||
|
 |
SHAFT REVOLUTIONS PER COUNT |
0.10 SINGLE REGISTER SINGLE TIER | ||
|
REGISTER QUANTITY |
1 | |||
|
 |
REGISTER FUNCTION |
ADD SINGLE REGISTER SINGLE TIER AND SUBTRACT SINGLE REGISTER SINGLE TIER | ||
|
 |
III STYLE DESIGNATOR |
SQUARE/RECTANGULAR CASED | ||
|
 |
NUMERAL DISPLAY METHOD |
DRUM | ||
|
 |
MOUNTING TYPE FOR WHICH DESIGNED |
PANEL SINGLE REGISTER SINGLE TIER | ||
|
 |
MOUNTING FACILITY TYPE AND QUANTITY |
1 FLANGE | ||
|
 |
FIGURE QUANTITY PER REGISTER |
3 SINGLE REGISTER SINGLE TIER | ||
|
 |
FIGURE HEIGHT |
0.250 INCHES NOMINAL SINGLE REGISTER SINGLE TIER | ||
|
 |
COLOR |
WHITE SINGLE REGISTER SINGLE TIER FIGURE | ||
|
 |
COLOR |
BLACK SINGLE REGISTER SINGLE TIER FIGURE BACKGROUND | ||
|
 |
ACTUATING DEVICE LOCATION |
LEFT SIDE SINGLE REGISTER SINGLE TIER | ||
