Electric Motors Inc 08634 25 Watt Alternating Current Motor NSN 6105-01-122-5908

Electric Motors Inc. 08634 25 Watt Alternating Current Motor NSN 6105-01-122-5908

Specifications:
Part: 08634 / Alt. ESP-L25EMIB  /  Alt. 4388-2
NSN: 6105-01-122-5908
Manufacturer: Electric Motors, Inc. USA

Additional Information:
Overall Height: 3.840 inches
Overall Length: 4.615 inches
Overall Width:  3.840 inches
Shaft Diameter: 0.312 inches nominal single end
Flat Depth: 0.042 inches nominal single end
Shaft Rotation Direction: Counterclockwise single end
Current Rating Method: LOAD
Features Provided: Thermal protective device and horizontal mounting position
Power Rating: 25.0 watts output
Length OF Shaft From Housing: 0.875 inches single end
Rotor Speed Rating IN RPM: 1500.0 single no load
Current Rating IN Amps: 1.100 single input
Connection Type AND Voltage Rating IN Volts: 115.0 line to neutral single output
Shaft END Characteristic: A5 single style single end
Special Features: 4 8-36 tapped mounting holes on each side of motor
Frequency IN Hertz: 60.0 output
Terminal Type AND Quantity: 2 wire lead

This item is in original packaging and appears to have never been used. New Old Stock.
