Electrodynamics D46B8CE Time Totalizing Meter NSN 6645-01-210-4388

Electrodynamics Time Totalizing Meter

P/N D46B8CE
NSN 6645-01-210-4388
Code 10736-8711

TERMINAL QUANTITY: 2
TERMINAL TYPE: SOLDER HOOK
MOUNTING TYPE: FLANGE
BODY DIAMETER: 0.650 INCHES MINIMUM AND
BODY DIAMETER: 0.690 INCHES MAXIMUM
CURRENT TYPE: DC
MOUNTING FLANGE WIDTH: 1.312 INCHES NOMINAL
CASE MATERIAL: ANY ACCEPTABLE
FLANGE HEIGHT: 0.938 INCHES MAXIMUM
MOUNTING CONFIGURATION: TWO 0.125 IN. DIA MTG HOLES SPACED 1.000 IN. APART C TO C
INDICATOR TYPE: DRUM REGISTER
VOLTAGE RATING: 6.0 VOLTS NOMINAL
MEASUREMENT UNIT: HOURS
UNIT TYPE: MOUNTED
HERMETIC PROTECTION: PROVIDED
MOVEMENT TYPE: ELECTRICAL
BODY DEPTH: 1.094 INCHES NOMINAL
SMALLEST INCREMENT INDICATED: 1.00
MOUNTING METHOD: SEMI-FLUSH
RESET FEATURE: NOT PROVIDED
MAXIMUM MEASUREMENT: 9999.00
MARKING COLOR: WHITE NUMERALS
BACKGROUND COLOR: DULL BLACK BACKGROUND
ELECTRICAL MOVEMENT TYPE: SYNCHRONOUS MOTOR
SPECIAL FEATURES: FLANGE SET BACK 0.125 IN. FROM BODY FRONT
