| MRC |
Requirements |
Characteristics |
| AJLA |
TEETH QUANTITY |
10 SINGLE END |
| BKPH |
TORQUE RATING AND TYPE |
2.9 INCH-POUNDS STALLED |
| TTQY |
TERMINAL TYPE AND QUANTITY |
4 SCREW |
| AAJV |
OVERALL WIDTH |
2.500 INCHES |
| AAJT |
OVERALL HEIGHT |
2.906 INCHES |
| CWHZ |
SHAFT END CHARACTERISTIC |
A22 SINGLE STYLE SINGLE END |
| ABWV |
SHAFT DIAMETER |
0.2500 INCHES NOMINAL SINGLE END |
| CWFX |
ROTOR SPEED RATING IN RPM |
10000.0 SINGLE NO LOAD |
| CNXS |
POWER RATING |
6.500 WATTS OUTPUT |
| FAAZ |
PHASE |
TWO INPUT |
| CWCS |
LENGTH OF SHAFT FROM HOUSING |
0.938 INCHES SINGLE END |
| ANPZ |
INCLOSURE FEATURE |
TOTALLY INCLOSED |
| BKPQ |
INCLOSURE SPECIFICATION |
COMMERCIAL |
| AAJU |
III OVERALL LENGTH |
6.748 INCHES |
| CWFY |
NOMINAL CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH |
1.876 INCHES |
| CWGD |
NOMINAL CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO HEIGHT |
1.876 INCHES |
| AXGY |
MOUNTING METHOD |
PAD |
| AXHR |
MOUNTING FACILITY TYPE AND QUANTITY |
4 UNTHREADED HOLE |
| FREQ |
FREQUENCY IN HERTZ |
60.0 OUTPUT |
| CBBL |
FEATURES PROVIDED |
HORIZONTAL MOUNTING POSITION AND VERTICAL MOUNTING POSITION |
| AYHE |
EXCITOR TYPE |
SEPARATELY EXCITED |
| ACDC |
CURRENT TYPE |
AC INPUT |
| BKPS |
CONTROL FIELD VOLTAGE TYPE AND RATING IN VOLTS |
72.0 AC |
| BFMF |
COOLING METHOD |
NONVENTILATED |
| CWGQ |
CONNECTION TYPE AND VOLTAGE RATING IN VOLTS |
72.0 LINE TO NEUTRAL SINGLE INPUT |
| BKPC |
CALIBRATION VOLTAGE OUTPUT TYPE IN VOLTS |
6.5 AC |
| BFLQ |
CALIBRATION SPEED IN RPM |
1000.0 |
