Product Overview
GE THED124020 20 Amp, 2 Poles, 240/480VAC, 250VDC Molded Case Circuit Breaker
General Electric THED series double pole single phase 20 ampere bolt-on molded case circuit breaker with maximum voltage rating of 480V trip type fixed thermal magnetic and standard interrupting rating of 25 kiloampere at 480V complete with load side lug terminals.
Specifications:
• Manufacturer: General Electric
• Cat. No.: THED124020
• Alternate Part No.: THED-124020
• Product Type: Circuit Breaker
• Type: THED
• No. of Poles: 2-Pole
• Phase: 1-Phase
• Voltage Rating: 240/480 Vac, 250 Vdc
• Amperage: 20 Ampere
• Connection: Bolt-On
• Protection: Thermal Magnetic
• Functions: (LI) Long-Time and Instantaneous
• Interrupting Rating: 65 Kiloampere At 240 Vac ,25 Kiloampere At 480 Vac, 20 Kiloampere At 250 Vdc
• Terminal Aluminum/Copper Load Lug
• Size: 4 1/8 Inch W X 3 3/8 Inch D X 6 5/16 Inch H
• Approval: Ul Listed
New surplus in manufacturers packaging. See photos for details.
XXQXX13
General Electric THED series double pole single phase 20 ampere bolt-on molded case circuit breaker with maximum voltage rating of 480V trip type fixed thermal magnetic and standard interrupting rating of 25 kiloampere at 480V complete with load side lug terminals.
Specifications:
• Manufacturer: General Electric
• Cat. No.: THED124020
• Alternate Part No.: THED-124020
• Product Type: Circuit Breaker
• Type: THED
• No. of Poles: 2-Pole
• Phase: 1-Phase
• Voltage Rating: 240/480 Vac, 250 Vdc
• Amperage: 20 Ampere
• Connection: Bolt-On
• Protection: Thermal Magnetic
• Functions: (LI) Long-Time and Instantaneous
• Interrupting Rating: 65 Kiloampere At 240 Vac ,25 Kiloampere At 480 Vac, 20 Kiloampere At 250 Vdc
• Terminal Aluminum/Copper Load Lug
• Size: 4 1/8 Inch W X 3 3/8 Inch D X 6 5/16 Inch H
• Approval: Ul Listed
New surplus in manufacturers packaging. See photos for details.
XXQXX13
