General Electric GE Synchroscope Type AB14 Category # 50101454ACAA2JAT

General Electric Synchroscope

Part # AB14

NSN 6625-01-205-7274

Category # 50101454ACAA2JAT

This device is used to measure the degree in which two systems, generators or power networks, are synchronized with each other

This unit is designed for 120 volt circuits and will operate properly on any voltage which does not differ more than 10 % from this value

NSN  Item Name

Technical Characteristics

6625-012057274  INDICATOR,SYNCHRONIZATION

MRC Requirements Characteristics SPCL SPECIAL TEST FEATURES CONFORMS TO MIL-I-16104A ABGL WIDTH 4.422 INCHES NOMINAL FEAT SPECIAL FEATURES SHOCK RES ABFN SCALE MARKING AND SURFACE FINISH LETTERS NONLUMINOUS AMNL PRESENTATION TYPE DIAL ASST POINTER TYPE INDICATING SINGLE POINTER FAAZ PHASE SINGLE ASKQ MARKING COLOR SPECIFIC USE EASY VISIBILITY ABRY LENGTH 6.957 INCHES NOMINAL ASKN INDIVIDUAL MARKING ARROW L AND RIGHT; SLOW; FAST ABTB MOUNTING HOLE DIAMETER 0.312 INCHES NOMINAL AXHR MOUNTING FACILITY TYPE AND QUANTITY 4 SCREW AND 4 UNTHREADED HOLE ANRL MOUNTING ARRANGEMENT STYLE FOUR HOLE/STUD RECTANGULAR/SQUARE HGTH HEIGHT 4.422 INCHES NOMINAL ZZZV FSC APPLICATION DATA TEST SET,ELECT. EQUIP. ACZB FREQUENCY RATING 60.0 HERTZ NOMINAL CBBL FEATURES PROVIDED MOUNTING HARDWARE AND WATERPROOF ACDC CURRENT TYPE AC ABKR CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH 3.376 INCHES NOMINAL ABKQ CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH 3.376 INCHES NOMINAL CWJK CASE MATERIAL STEEL BNHZ ACCURACY RATING 2.0 DEGREE ANGULAR CALIBRATION RANGE SINGLE INDICATOR SINGLE SCALE ACYN AC VOLTAGE RATING 120.0 VOLTS NOMINAL ASKX ELECTRICAL CONNECTION QUANTITY 4

This is a surplus item with some wear from storage but not signs of use or installation

Item is untested by the seller
