Product Overview
LightMaster Programmable Lighting Control LM-24 ILC, 93002524
Model: LM-24
Relays: up to 24
Width: 24"
Height: 36"
Depth: 4"
New Surplus still in original box. There are some cosmetic scratches due to shipment. There is no key for the lock on the enclosure.
LightMaster Lighting Control Panels
The LightMaster programmable lighting control panel is suitable for all your lighting control needs. LightMaster panels range in size from 8 to 48 relays and are equipped with CAT-5 RJ-45 connectors for LightSync dat line devices and interconnecting panels. Panels include a keyboard/LCD display along with RS232, RS485, or an optional TCP/IP port to enable PC control and programming. Add-on modules are available if you require connecting to BAS, theatrical, or security systems.
- 365-day programmable Lighting Control Panel
- All products Made in the USA
- LightSync™ switch and accessory ready
- RS232, RS485, and TCP/IP connectivity available
- Equipped for standalone or network use
- Connect up to 128 panels and 254 LightSync devices together
- Add-on modules available for BAS control and monitoring
Relays:
- 2R9 latching relay: 120 - 277VAC @ 20 Amp for ballast and resistive loads 180,000A SCCR.
- 2-Pole latching contactors: 208-480 VAC, 20 Amps for ballast and resistive loads.
Safeguards:
- Power surge and spike suppression up to 123 volts on the 24VAC power input
- Data line surge and spike suppression up to 8kv direct and 15kv through air (optional).
- Memory retention for firmware and programming up to 10 years
- Real-Time-Clock time retention 45 days or greater without power
Physical:
- Provided with pre-drilled mounting holes
- Provided with a removable hinged locking door for flush or surface mounting
- High voltage barriers separate Normal/Emergency and Class 1/Class 2 wiring
Electrical:
- 120 or 277 VAC @ 1 Amp. (347 VAC optional)
Capacities:
- 1 to 48 relays (see table above)
- Contact ILC for contactor capacities
Options:
- Panels may be fitted with a wide variety of options such as: TCP/IP, modem, DMX 512, Metesys N2, Modbus, BACnet, LonWorks, and flush mount panel cover
Operating Environment:
- Location: Interior space
- Operating Temperature: 0° to 50° C
- Humidity: 10% - 90% Non-condensing
- Atmosphere: Non-explosive/corrosive
- Vibration: Stationary
Certifications and Approvals:
- UL 508
- UL 916
- FCC Part 15
- Title 24
- ASHRAE compliant
- LEED compliant
