| MRC |
Requirements |
Characteristics |
| AKDX |
WINDING QUANTITY |
1 SINGLE COMPONENT |
| CRBZ |
WINDING OPERATING CURRENT |
250.0 MILLIAMPERES DC MAXIMUM SINGLE COMPONENT SINGLE WINDING |
| THSD |
THREAD SERIES DESIGNATOR |
UNF SINGLE GROUP |
| CMLP |
THREAD QUANTITY PER INCH |
32 SINGLE GROUP |
| TTQY |
TERMINAL TYPE AND QUANTITY |
2 THREADED STUD |
| AARG |
RELIABILITY INDICATOR |
NOT ESTABLISHED |
| BKPL |
RATING METHOD |
ELECTRICAL SINGLE COMPONENT SINGLE WINDING |
| ACYF |
INDUCTANCE TYPE |
FIXED |
| ACYV |
INDUCTANCE RATING |
200.00 MILLIHENRIES NOMINAL SINGLE COMPONENT SINGLE WINDING |
| AKNA |
INCLOSURE TYPE |
FULLY INCLOSED |
| CQJX |
NOMINAL THREAD SIZE |
0.190 INCHES SINGLE GROUP |
| AXGY |
MOUNTING METHOD |
THREADED STUD SINGLE GROUP |
| AKPV |
MOUNTING FACILITY QUANTITY |
4 SINGLE GROUP |
| ACZB |
FREQUENCY RATING |
120.0 HERTZ NOMINAL SINGLE COMPONENT |
| CRGS |
DC RESISTANCE RATING IN OHMS |
0.700 SINGLE COMPONENT SINGLE WINDING |
| ABKR |
CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH |
2.688 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| ABKQ |
CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH |
3.313 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| ADAT |
BODY WIDTH |
3.688 INCHES NOMINAL |
| ADAQ |
BODY LENGTH |
4.313 INCHES NOMINAL |
| ADAU |
BODY HEIGHT |
4.500 INCHES NOMINAL |
