Marshalltown 4.5" Dial Indicating Pressure Gauge NSN 6685-00-684-1494 P/N G18313

Marshall Town

(No reviews yet) Write a Review
$93.71
Marshalltown 4.5" Dial Indicating Pressure Gauge NSN 6685-00-684-1494 P/N G18313
SKU:
IF_2447EF1A
Adding to cart… The item has been added

Product Overview

MARSHALL TOWN DIAL INDICATING PRESSURE GAUGE

NSN: 6685-00-684-1494

Part Number: G18313



OVERALL DEPTH: 1.812 INCHES NOMINAL
BOLT CIRCLE DIAMETER: 5.500 INCHES NOMINAL
MOUNTING HOLE DIAMETER: 0.281 INCHES NOMINAL
MOUNTING HOLE QUANTITY: 3
OVERALL DIAMETER: 6.312 INCHES NOMINAL
CASE MATERIAL: ALUMINUM, DIE CAST
CASE SURFACE TREATMENT: ENAMEL, BLACK
GRADUATION UNIT: 1.0 POUNDS PER SQUARE INCH
ACTUATION TYPE: SINGLE BOURDON TUBE
ADJUSTABILITY: ADJUSTABLE
SCALE RANGE: 0.0 TO 15.0 POUNDS PRESSURE PER SQUARE INCH
SCALE NAME: PRESSURE
DIAL SIZE: 4-1/2 IN. DIA
CONNECTION QUANTITY: 1
POINTER COLOR: BLACK
POINTER TYPE: INDICATING
SCALE TYPE: SINGLE
SCALE SMALLEST INCREMENT: 0.125 POUNDS PER SQUARE INCH
CONNECTION TYPE: EXTERNAL
MOUNTING METHOD: FLUSH PANEL
SCALE ACCURACY: PORM 1/2 PCT FULL RANGE
ACTUATING ELEMENT MATERIAL: STEEL, STAINLESS
SCALE INSCRIPTION/BACKGROUND COLOR: BLACK FIGURES ON WHITE BACKGROUND
CONNECTION LOCATION: BACK, LOWER
BEZEL TYPE: THREAD
PROTECTIVE CRYSTAL MATERIAL: GLASS
CONNECTION SIZE: 0.250 IN. NPT DIA
CONNECTOR TYPE VENT: NOT PROVIDED
MATERIAL: ALUMINUM
SURFACE TREATMENT: ENAMEL




New surplus in MIL packaging, see photos for details.
