Name: Metal Tube Assembly P/N 10934509 NSN 4710-00-955-5499 M-578
Brand: EW Packaging Cor
SKU: IF_4F487B35
Price: 94.91 USD
Availability: InStock

Product Overview

Metal Tube Assembly P/N 10934509 NSN 4710-00-955-5499 M-578

Part No. 10934509

NSN: 4710-00-955-5499

Specifications :

Material : steel, MIL-T-3520, Type 3 Comp 1010

Wall thickness : .049"

Tube outside diameter : .625"

Burst pressure : 7500 LB

Seat angle : 12°

End connection style : swivel nut w/ loose clinch sleeve

NSN
Item Name

Technical Characteristics

4710-009555499

TUBE ASSEMBLY,METAL

MRC	Requirements	Characteristics
AAGT	WALL THICKNESS	0.049 INCHES NOMINAL
AHSA	TUBING MATERIAL	STEEL, MIL-T-3520, TYPE 3, COMP 1010 OR STEEL, MIL-T-3520, TYPE 3, COMP 1025
BBYQ	TUBE OUTSIDE DIAMETER	0.625 INCHES NOMINAL
THSD	THREAD SERIES DESIGNATOR	UNF SINGLE END
AAJF	THREAD DIRECTION	RIGHT-HAND SINGLE END
AAJD	THREAD CLASS	3B SINGLE END
FEAT	SPECIAL FEATURES	ENAMEL COLOR OLIVE DRAB; 7500 LB BURST PRESSURE
AJFY	SEAT ANGLE IN DEG	12.0 SINGLE END
CQJX	NOMINAL THREAD SIZE	0.875 INCHES SINGLE END
AFQW	MATING END QUANTITY	2 SINGLE END
MATT	MATERIAL	STEEL SINGLE END
AGAV	III END ITEM IDENTIFICATION	M110 HOWITZER FAMILY
ARJD	DESIGN FORM	PREBENT
AJFX	END CONNECTION STYLE	SWIVEL NUT WITH LOOSE OR INTEGRAL CLINCH SLEEVE SINGLE END
BZRS	END CONNECTION SPEC/STD	MIL,MS21921,PART NO. MS21921-10,MIL,MS21922,PART NO. MS21922-10
