| MRC |
Requirements |
Characteristics |
| FEAT |
SPECIAL FEATURES |
CLEANED FOR OXYGEN SERVICE |
| ADAV |
OVERALL DIAMETER |
4.969 INCHES NOMINAL |
| ABFY |
OVERALL DEPTH |
2.406 INCHES NOMINAL |
| ATEQ |
SCALE TYPE |
SINGLE |
| AWAG |
SCALE SMALLEST INCREMENT |
5.0 POUNDS PER SQUARE INCH |
| AQFZ |
SCALE NAME |
PRESSURE |
| ASTW |
SCALE MARKING |
USE NO OIL |
| APSK |
SCALE RANGE |
+0.0/+600.0 POUNDS PRESSURE PER SQUARE INCH |
| BGKZ |
SCALE INSCRIPTION/BACKGROUND COLOR |
BLACK MARKINGS ON WHITE BACKGROUND |
| BGKS |
SCALE ACCURACY |
1 PCT ENTIRE RANGE |
| BHMF |
PROTECTIVE CRYSTAL MATERIAL |
PLASTIC |
| ASST |
POINTER TYPE |
INDICATING AND REFERENCE |
| ASSS |
POINTER COLOR |
BLACK AND RED |
| ZZZT |
NONDEFINITIVE SPEC/STD DATA |
A DESIGN AND A TYPE |
| AXGY |
MOUNTING METHOD |
FLUSH |
| ABTJ |
MOUNTING HOLE QUANTITY |
3 |
| ABTB |
MOUNTING HOLE DIAMETER |
0.219 INCHES NOMINAL |
| ANBJ |
GRADUATION UNIT |
50.0 POUNDS PER SQUARE INCH |
| ARCH |
DIAL SIZE |
4-1/2 IN. DIA |
| AWLS |
CONNECTION TYPE |
EXTERNAL |
| BHMK |
CONNECTOR TYPE VENT |
NOT PROVIDED |
| BHMG |
CONNECTION SIZE |
0.250 IN. TUBE |
| ASMM |
CONNECTION QUANTITY |
1 |
| BGRY |
CONNECTION LOCATION |
BACK |
| ADTV |
CASE MATERIAL |
ALUMINUM |
| ADTY |
CASE SURFACE TREATMENT |
ENAMEL, GRAY |
| ABKG |
BOLT CIRCLE DIAMETER |
5.375 INCHES NOMINAL |
| APCS |
ADJUSTABILITY |
ADJUSTABLE |
| APCM |
ACTUATION TYPE |
SINGLE BOURDON TUBE |
| BGKY |
ACTUATING ELEMENT MATERIAL |
NICKEL-COPPER-ALUMINUM ALLOY |
