Product Overview
Moore Model SSPH Fluidic Flowmeter Â
Model #Â 14CNB21S
B/M MST10819-002
Specifications :
Range : 0 - 7 GPM
K-factor : 431.04
Pulses : Gal
Enclosure type : NEMA 4
Power requirements : 120V +10%/-15% 50/60 Hz 13W max
Input :
Deflection sensor : Terminals 9, 10, 11, 12
Open circuit voltage : 10 VDC max
Short circuit current : 6 mA max
Output :
Current output, 4 to 20 mA Isolated (Terminals 4 & 5)
Max current : 35 mAdc
Max voltage : 18.9 Vdc
Span adjustment : 30% of max span
Linearity : within 0.25% of span
0-100% step response : 4 sec. to 10 sec. depends on range board
Ambient temperature effect : within +/- 0.02% of span per degrees C
Output load effect : less than 0.01% of span for 0 to 600 ohms
Supply voltage effect : less than 0.01% of span for +/-10% change of supply
Includes manualÂ
Model #Â 14CNB21S
B/M MST10819-002
Specifications :
Range : 0 - 7 GPM
K-factor : 431.04
Pulses : Gal
Enclosure type : NEMA 4
Power requirements : 120V +10%/-15% 50/60 Hz 13W max
Input :
Deflection sensor : Terminals 9, 10, 11, 12
Open circuit voltage : 10 VDC max
Short circuit current : 6 mA max
Output :
Current output, 4 to 20 mA Isolated (Terminals 4 & 5)
Max current : 35 mAdc
Max voltage : 18.9 Vdc
Span adjustment : 30% of max span
Linearity : within 0.25% of span
0-100% step response : 4 sec. to 10 sec. depends on range board
Ambient temperature effect : within +/- 0.02% of span per degrees C
Output load effect : less than 0.01% of span for 0 to 600 ohms
Supply voltage effect : less than 0.01% of span for +/-10% change of supply
Includes manualÂ
