Product Overview
Samlex IDC-360-B24 360Watt Fully Isolated DC-DC Converter In 20-35VDC/Out 24VDC
IDC-360 series is a complete line of high efficiency 360 Watt isolated DC-DC converters suitable for applications requiring galvanic isolation between the input and the output. IDC-360B-24 isolated DC-DC converter provides a highly regulated output DC voltage of 24.5 Volts for an input DC voltage range of 20-35 Volts and rated output current of 15 Amps (at 35 Volts input). Features of this isolated DC-DC converter include compact housing fold-back current limiting and protection against short circuit overheating overvoltage and reverse polarity connection. The unit comes with 1/4 push-on flat blade quick disconnect connectors. IDC-360B-24 isolated DC-DC converter is EMI/EMC compliant and conforms to European standards EN50081-1 (for EMI) EN50082-1 (for EMC) and the European Automotive Directive 95/54/CE.
Design Features:
-Fully Isolated
-Short Circuit Protected
-Current Limited
-CE Approved
Applications:
-Earth moving equipment
-Heavy trucks
-Buses
-Marine vehicles
-CB radios
-24 Volt lighting systems
-AM/FM sound systems
New surplus in manufacturers packaging. See photo for details.
XXQXX10
IDC-360 series is a complete line of high efficiency 360 Watt isolated DC-DC converters suitable for applications requiring galvanic isolation between the input and the output. IDC-360B-24 isolated DC-DC converter provides a highly regulated output DC voltage of 24.5 Volts for an input DC voltage range of 20-35 Volts and rated output current of 15 Amps (at 35 Volts input). Features of this isolated DC-DC converter include compact housing fold-back current limiting and protection against short circuit overheating overvoltage and reverse polarity connection. The unit comes with 1/4 push-on flat blade quick disconnect connectors. IDC-360B-24 isolated DC-DC converter is EMI/EMC compliant and conforms to European standards EN50081-1 (for EMI) EN50082-1 (for EMC) and the European Automotive Directive 95/54/CE.
Design Features:
-Fully Isolated
-Short Circuit Protected
-Current Limited
-CE Approved
Applications:
-Earth moving equipment
-Heavy trucks
-Buses
-Marine vehicles
-CB radios
-24 Volt lighting systems
-AM/FM sound systems
New surplus in manufacturers packaging. See photo for details.
XXQXX10
