Stuffing Tube Packing Nut MIL Spec PN: M24235/9-065-E, NSN: 5975-01-178-4506

(No reviews yet) Write a Review
$14.14
Stuffing Tube Packing Nut MIL Spec PN: M24235/9-065-E, NSN: 5975-01-178-4506
SKU:
IF_9D2FB42D
Adding to cart… The item has been added

Product Overview

Stuffing Tube Packing Nut MIL Spec PN: M24235/9-065-E, NSN: 5975-01-178-4506

PN: M24235/9-065-E

NSN: 5975-01-178-4506

5975-011784506

PACKING NUT,STUFFING TUBE
MRC Requirements Characteristics
STYL STYLE DESIGNATOR PLAIN-W/COUNTERBORE
MARK SPECIAL MARKINGS EE
ASDB WIDTH ACROSS FLATS 1.375 INCHES NOMINAL
ADGV THREAD RELIEF LENGTH 0.188 INCHES NOMINAL
AASA THREAD LENGTH 0.687 INCHES NOMINAL
ABHP OVERALL LENGTH 1.063 INCHES NOMINAL
FEAT SPECIAL FEATURES 250 MICROINCH INTERIOR SURFACE
BGBD SIZE 0.812 INCHES NOMINAL
MATT III MATERIAL COPPER ALLOY OVERALL
CSNZ FIRST END CHAMFER ANGLE 45.0 DEGREES NOMINAL
AAWZ COUNTERBORE DEPTH 0.250 INCHES NOMINAL
AAWY COUNTERBORE DIAMETER 0.938 INCHES NOMINAL
ADGE BORE LENGTH 0.813 INCHES NOMINAL
ABXV BORE DIAMETER 0.812 INCHES NOMINAL


Used surplus, please see photos for more.







XXQXX07
