Product Overview
Teledyne Relays m39016/15-033L J412D-26WL Through Hole Relay
Supplier: Teledyne Relays
Part No: M39016/15-033L
RoHS: Yes
HTS: 8536410020
ECCN: EAR99
Prop: California Prop 65
Alias/AKA: J412D-26WL
Termination Style: PC Pin
Pin Count: 8
Dimension: 9.4 x 10.29 x 6.86 mm
Maximum AC Voltage Rating: 115 V
Type: Established Reliability Relay
Maximum DC Voltage Rating: 28 V
Led Indicator: No Coil
Suppression Diode: Yes
Coil Current: 16.99 mA
Seal: Hermetic Seal
Contact Arrangement: DPDT Relay
Construction: Non-Latching
DC Coil Voltage: 26.5 V
Push to Test Button: No
Product Weight: 2.55 g
Contact Material: Precious Metal/Gold Plated
Mounting: Through Hole
Operate Time: 2 ms
Maximum Power Rating: N/A
Minimum Dropout Voltage: 0.89
VDC Package Type: TO-5
Family: 412
Operating Temperature: -65 to 125 °C
Contact Form: 2 Form C
Maximum Pick-Up Voltage: 18 VDC
Maximum Current Rating: 1DC,0.25AC A
Coil Resistance: 1.56 KOhm
Unit of Measure: Per Each
New Surplus Stock. See photos for details.
