Product Overview
Thomas & Betts 54755 Copper C-Tap 1-4/0 Branch 2/0-8 Die Code 76 Color Code Blue
UPC: 78621054755
Minimum Tap Conductor Size: 8 AWG
Maximum Tap Conductor Size: 2/0 AWG
Die Index: 76
Body Material: High Conductivity Plain Wrought Copper
Approval: UL, CSA
Additional Information: Overall Dimension 3/4 Inch Width x 1-15/16 Inch Height; Color Blue; Number of Crimps 1
Item Number: 54755
Voltage Rating: 600 Volt
Shape: C
Number of Taps: 1
Conductor Material: Copper
Minimum Run Conductor Size: 1 AWG
Maximum Run Conductor Size: 4/0 AWG
CATALOG DESCRIPTION: COPPER C-TAP, WIRE RANGE MAIN: 1-4/0 BRANCH 2/0-8, PLAIN FINISH, DIE CODE 76, DIE COLOR CODE BLUE, NUMBER OF CRIMPS 2
Category: Large Terminals & Connectors
Full Technical Description: 1 AWG min. Run Conductor Size; 4/0 AWG Max. Run Conductor Size; 8 AWG min. Tap Conductor Size; 2/0 AWG Max. Tap Conductor Size; C Shape; Copper Conductor Material; UL, CSA Approval; 600 Volt Voltage Rating; High Conductivity Plain Wrought Copper Body Material; 76 Die Index; 1 Tap(S); Overall Dimension 3/4 Inch Width X 1-15/16 Inch Height; Color Blue; Number of Crimps 1
Manufacturer: ABB, Inc. - Thomas & Betts
Manufacturer Brand: T&B Corp.
Product Description: T&B 54755 1-4/0 BLUE COP C-TAP
Sub-Category: Compression Cable Tap
New surplus without manufacturers packaging. See photos for details.
XXQXX10
UPC: 78621054755
Minimum Tap Conductor Size: 8 AWG
Maximum Tap Conductor Size: 2/0 AWG
Die Index: 76
Body Material: High Conductivity Plain Wrought Copper
Approval: UL, CSA
Additional Information: Overall Dimension 3/4 Inch Width x 1-15/16 Inch Height; Color Blue; Number of Crimps 1
Item Number: 54755
Voltage Rating: 600 Volt
Shape: C
Number of Taps: 1
Conductor Material: Copper
Minimum Run Conductor Size: 1 AWG
Maximum Run Conductor Size: 4/0 AWG
CATALOG DESCRIPTION: COPPER C-TAP, WIRE RANGE MAIN: 1-4/0 BRANCH 2/0-8, PLAIN FINISH, DIE CODE 76, DIE COLOR CODE BLUE, NUMBER OF CRIMPS 2
Category: Large Terminals & Connectors
Full Technical Description: 1 AWG min. Run Conductor Size; 4/0 AWG Max. Run Conductor Size; 8 AWG min. Tap Conductor Size; 2/0 AWG Max. Tap Conductor Size; C Shape; Copper Conductor Material; UL, CSA Approval; 600 Volt Voltage Rating; High Conductivity Plain Wrought Copper Body Material; 76 Die Index; 1 Tap(S); Overall Dimension 3/4 Inch Width X 1-15/16 Inch Height; Color Blue; Number of Crimps 1
Manufacturer: ABB, Inc. - Thomas & Betts
Manufacturer Brand: T&B Corp.
Product Description: T&B 54755 1-4/0 BLUE COP C-TAP
Sub-Category: Compression Cable Tap
New surplus without manufacturers packaging. See photos for details.
XXQXX10
